Intel® Desktop Board DQ45CB


Intel® Desktop Board DQ45CB supporting Intel® vPRO™ Technology is designed to bring users unprecedented ability to remotely maintain, manage, and protect their business PCs. Pair this board with any 45nm Intel® Core™ 2 Quad or Intel® Core™ 2 Duo processor to get the latest performance in an energy-efficient package. Enjoy new features such as dual-DVI video output and eSATA port on back-panel, as well as value add software enhancing security and remote management options of your system.

Intel® Desktop Board DQ45CB supports Intel® AMT 5.0 Professional, Intel® Trusted Platform Module, and is Microsoft Windows Vista* Premium WHQL certified.

Product information

Features and benefits

Form Factor MicroATX (9.60 inches by 9.60 inches [243.84 millimeters by 243.84 millimeters])
Processor

Click View supported processors for the most current list of compatible processors.

At product launch, this desktop board supports:

Memory
  • Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) socket
  • Support for DDR2 800/667 MHz DIMMs
  • Support for up to 8 GBΣ of system memory
Audio Intel® High Definition Audio subsystem in the following configuration:
5.1 audio subsystem using the ADI AD1882 audio codec
Video Intel® Graphics Media Accelerator 4500 onboard graphics subsystem with integrated DVI-I and DVI-D graphics output
LAN Support Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel® 82567LM Gigabit Ethernet Controller
Peripheral Interfaces
  • Up to 12 USB 2.0 ports
  • Six Serial ATA 3.0 Gb/s ports, including 1 eSATA back port with RAID 0, 1, 5, 10 support
  • Two IEEE-1394a ports (1 external port, 1 internal header)
  • One serial port via header
Expansion Capabilities
  • One PCI Conventional* bus add-in card connector
  • Two PCI Express* x1 bus add-in card connectors
  • One PCI Express* 2.0 x 16 bus add-in card connector


Related products

Processors
Chipsets


Price(Pkr) 9800

Intel® Desktop Board DP45SG


Welcome to the extreme performance platform brought to you by Intel® Desktop Board DP45SG, supporting the Intel® Core™2 Extreme processor with up to 1333 FSB. Built in the full size ATX, this board comes with dual PCI Express* (PCIe) 2.0 x16 graphics connectors, DDR-3 1333 support and overclocking capabilities. Intel® Desktop Board DP45SG will take your gaming experience to a higher level.
Intel Desktop Board DP45SG supports Dolby Home Theater* and is Microsoft Windows Vista* Premium WHQL certified.
Product information
Product brief
File Type/Size: PDF 1425KB
View available configurations
View supported processors
Latest BIOS and driver updates
Features and benefits
Form factor
ATX (11.60 inches by 9.60 inches [294.64 millimeters by 243.84 millimeters])
Processor
View supported processors for the most current list of compatible processors.
At product launch, this desktop board supports:
Support for an Intel® Core™2 Extreme processor in an LGA775 socket
Support for an Intel® Core™2 Quad processor in an LGA775 socket
Support for an Intel® Core™2 Duo processor in an LGA775 socket
Support for an Intel® Pentium® processor in an LGA775 socket
Support for an Intel® Celeron® processor in an LGA775 socket
Support for an Intel® Celeron® processor 400 sequence in an LGA775 socket
Memory
Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
Support for DDR3 1333/1066/800 MHz DIMMs
Support for up to 8 GBΣ of system memory
Chipset
Intel® P45 Express Chipset
Audio
Intel® High Definition Audio subsystem in the following configuration:
8-channel (7.1) audio subsystem with five analog audio outputs and one optical S/PDIF digital audio output using the IDT 92HD73E audio codec
Video
Dual PCI Express* (PCIe) 2.0x16 slots with ATI Crossfire* technology support
Full support of Next Generation ATI Crossfire
LAN Support
Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel® 82567LF Gigabit Ethernet Controller
Peripheral Interfaces
Up to 12 USB 2.0 ports (6 back ports and 6 via headers)
Six Serial ATA 3.0 Gb/s ports, including 1 eSATA back port with RAID 0, 1, 5, 10 support
Two IEEE-1394a ports (1 external port, 1 internal header)
Consumer IR receiver and emitter (via internal headers)
One serial port via header
Expansion Capabilities
Two PCI* Express 2.0 x1 and three PCI expansion slots
Related products
Processors
Intel® Core™2 Extreme processor
Intel® Core™2 Quad processor
Intel® Core™2 Duo processor
Intel® Pentium® processor
Intel® Celeron® processor
Intel® Celeron® processor 400 sequence
Chipsets
Intel® P45 Express Chipset


Price(pkr) 11200.

Intel® Desktop Board D975XBX2


If you've got the POWER…the SPEED…the PERFORMANCE on your team, then you've got the WINNING EDGE.With the Intel® Desktop Board D975XBX2, supporting the Intel® Core™ 2 Extreme processor, your desktop PC will become the ultimate weapon. You will scream through the latest games, level after level.Add the world's best gaming processor and the D975XBX2 to your game strategy - a combination so BAD that it's GOOD.The Intel® Desktop Board D975XBX2 is Microsoft Windows Vista* Premium Ready. The Intel® 975X Express Chipset fully supports the visually stunning Windows Aero* user interface with amazing transition effects and realistic animations.
Product information
View Available Configurations
Get Windows* Hardware Quality Labs (WHQL) Information
View Industry Specifications
View Regulatory Compliance Information
Features and benefits
Form Factor
ATX (12.00 inches by 9.60 inches [304.80 millimeters by 243.84 millimeters])
Processor
Support for Intel® Core™2 Quad processor in an LGA775 socket with a 1066 MHz system bus
Support for Intel® Core™2 Extreme processor in an LGA775 socket with a 1066 MHz system bus
Support for an Intel® Core™2 Duo processor in an LGA775 socket with a 1066 MHz system bus
Support for an Intel® Pentium® Processor Extreme Edition in an LGA775 socket with a 1066 or 800 MHz system bus
Support for an Intel® Pentium® 4 Processor Extreme Edition supporting Hyper-Threading Technology◊ (in an LGA775 socket with a 1066 MHz system bus)
Support for an Intel® Pentium® D processor in an LGA775 socket with an 800 MHz system bus
Support for an Intel Intel® Pentium® 4 processor supporting Hyper-Threading Technology◊ (in an LGA775 socket with an 800 MHz system bus)
View all supported processors
Memory
Four 240-pin DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
Support for DDR2 800, DDR2 667, or DDR2 533 MHz DIMMs
Support for up to 8 GBΣ of system memory
Support for ECC and non-ECC memory
Chipset
Intel® 975X Express Chipset
Audio
Intel® High Definition Audio subsystem in one of the following configurations:
8-channel (7.1) audio subsystem with five analog audio outputs and two S/PDIF digital audio outputs (coaxial and optical) using the Sigmatel* 9274D audio codec
6-channel (5.1) audio subsystem with three analog audio outputs using the Sigmatel 9227 audio codec
ATI CrossFire* Multi-GPU Platform Support
ATI CrossFire technology enables two ATI graphics cards to work together for ultimate 3D gaming performance and visual quality
I/O Control
Legacy I/O controller for diskette drive, serial, parallel, and PS/2* ports
LAN Support
Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel® 82573E/82573L Gigabit Ethernet Controller
Peripheral Interfaces
Eight USB 2.0 ports
Four Serial ATA interfaces with RAID support (four additional interfaces available with optional discrete RAID controller)
One parallel ATA IDE interface with UDMA 33, ATA-66/100 support
One diskette drive interface
One serial port
One parallel port
PS/2* keyboard and mouse ports
Expansion Capabilities
Two PCI Conventional* bus add-in card connectors (SMBus routed to both PCI Conventional bus add-in card connectors)
One Primary PCI Express* x16 (electrical x16 or x8) bus add-in card connector
One Secondary PCI Express* x16 (electrical x8) bus add-in card connector
One PCI Express* x16 (electrical x4) bus add-in card connector
Microsoft Vista* Premium Ready
With a PC built with Intel® Core™2 Duo or Intel® Core™2 Quad processors, and the Intel® Desktop Board, you can experience a more responsive and manageable environment of Microsoft Windows Vista* including a new visual sophistication of the Windows Aero* interface.
Related products
Processors
Intel® Core™2 Extreme processor
Intel® Core™2 Duo processor
Intel® Pentium® Processor Extreme Edition
Intel® Pentium® 4 Processor Extreme Edition supporting Hyper-Threading Technology◊
Intel® Pentium® D processor
Intel® Pentium® 4 Processor supporting Hyper-Threading Technology
Chipsets
Intel® 975X Express Chipset





Price(pkr)15200.

Intel® Desktop Board DX58SO


The Intel® Desktop Board DX58SO is designed to unleash the power of the all new Intel® Core™ i7 processors with support for up to eight threads of raw CPU processing power, triple channel DDR3 memory and full support for ATI CrossfireX* technology. Today’s PC games like Far Cry 2* and Call of Duty: World at War* need a computing platform that delivers maximum multi-threaded CPU support and eye-popping graphics support.
Product information
Download product brief
File Type/Size: PDF 1863KB
View available configurations
View supported processors
Latest BIOS and driver updates
Features and benefits
Form factor
ATX (12.00 inches by 9.60 inches [304.80 millimeters by 243.84 millimeters])
Processor
Click View supported processors for the most current list of compatible processors. At product launch, this desktop board supports:
Support for a Intel® Core™ i7 processor in an LGA1366 socket
Memory
Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
Support for DDR3 1600 MHzς, DDR3 1333 MHzς, DDR3 1066 MHz
Support for up to 16 GBς of system memory
Chipset
Intel® X58 Express Chipset
Audio
Intel® High Definition Audio subsystem in the following configuration:
8-channel (7.1) Dolby Home Theater* Audio subsystem with five analog audio outputs and two S/PDIF digital audio outputs (coaxial and optical) using the Sigmatel* 9274D audio codec
Video
Nvidia SLI* and ATI CrossFire* multi-GPU platform support enables two graphics cards to work together for ultimate 3D gaming performance and visual quality
Full support of next-generation ATI CrossFire* and Nvidia SLI*
LAN support
Gigabit (10/100/1000 Mbits/sec) LAN subsystem
Peripheral interfaces
Twelve USB 2.0 ports (8 external ports, 2 internal headers)
Six Serial ATA 3.0 Gb/s ports, including 2 eSATA port with RAID support supplied by a Marvell* controller
Two IEEE-1394a ports (1 external port, 1 internal header)
Consumer IR receiver and emitter (via internal headers)
Expansion capabilities
One PCI Conventional* bus add-in card connectors (SMBus routed to PCI Conventional bus add-in card connector)
One primary PCI Express* 2.0 x16 (electrical x16) bus add-in card connector
One secondary PCI Express 2.0 x16 (electrical x16) bus add-in card connector
One PCI Express* 1.0a x16 (electrical x4) bus add-in card connector
Related products
Processors
Intel® Core™ i7 processor
Intel® Core™ i7 processor Extreme Edition
Chipsets
Intel® X58 Express Chipset
Price(pkr) 20500.

Intel® Desktop Board DX48BT2


Pulse-pounding gaming and high-powered multimedia experiences require the ultimate in performance from your processor and motherboard. Intel® Desktop Board DX48BT2 is designed to unleash the power of Intel® Core™2 Extreme processors. With support for 1600 MHz front side bus, fast DDR3 memory and overclocking, Intel Desktop Board DX48BT2 delivers the gaming performance you deserve.Intel Desktop Board DX48BT2 supports Dolby Home Theater* and Microsoft Windows Vista* Premium WHQL certified.
Product information
Download product brief
File Type/Size: PDF 1506KB
View available configurations
View supported processors
Latest BIOS and driver updates
Features and benefits
Form factor
ATX (12.00 inches by 9.60 inches [304.80 millimeters by 243.84 millimeters])
Processor
Support for both 45nm & 65nm Intel® Core™2 Quad processors in an LGA775 socket with a 1600, 1333 or 1066 MHz system bus
Support for both 45nm & 65nm Intel® Core™2 Extreme processors in an LGA775 socket with a 1600, 1333 or 1066 MHz system bus
Support for both 45nm & 65nm Intel® Core™2 Duo processors in an LGA775 socket with a 1333 or 1066 MHz system bus
Support for an Intel® Pentium® processor in an LGA775 socket with an 800 MHz system bus
View all supported processors
Memory
Four 240-pin DDR3 SDRAM Dual Inline Memory Module (DIMM) sockets
Support for DDR3 1600 MHz, DDR3 1333 MHz, DDR3 1066 MHz, or DDR3 800 MHz DIMMs
Support for up to 8 GBΣ of system memory
Chipset
Intel® X48 Express Chipset
Audio
Intel® High Definition Audio subsystem in the following configuration:
8-channel (7.1) Dolby Home Theater* Audio subsystem with five analog audio outputs and two S/PDIF digital audio outputs (coaxial and optical) using the Sigmatel* 9274D audio codec
ATI CrossFire* multi-GPU platform support
ATI CrossFire technology enables two ATI* graphics cards to work together for ultimate 3D gaming performance and visual quality
Full support of next-generation ATI CrossFire*
I/O control
I/O controller for Consumer IR
LAN support
Gigabit (10/100/1000 Mbits/sec) LAN subsystem using the Intel® 82566DC Gigabit Ethernet Controller
Peripheral interfaces
Twelve USB 2.0 ports (8 external ports, 2 internal headers)
Six Serial ATA 3.0 Gb/s ports, including 2 eSATA port with RAID support supplied by a Marvell* controller
Two IEEE-1394a ports (1 external port, 1 internal header)
Consumer IR receiver and emitter (via internal headers)
One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support (2 devices supported)
Expansion capabilities
Two PCI Conventional* bus add-in card connectors (SMBus routed to both PCI Conventional bus add-in card connectors)
One primary PCI Express* 2.0 x16 (electrical x16) bus add-in card connector
One secondary PCI Express 2.0 x16 (electrical x16) bus add-in card connector
One PCI Express* 1.0a x16 (electrical x4) bus add-in card connector
Microsoft Windows Vista* Premium ready
With a PC built with Intel® Core™2 Duo or Intel® Core™2 Quad processors, and the Intel® Desktop Board, you can experience a more responsive and manageable environment of Microsoft Windows Vista* including a new visual sophistication of the Microsoft Windows Aero* interface.
Related products
Processors
Intel® Core™2 Extreme processor
Intel® Core™2 Quad processor
Intel® Core™2 Duo processor
Intel® Pentium® Processor
Chipsets
Intel® X48 Express Chipset


Price(pkr) 23000.

Intel® Core™ i7 940 Processor Extreme Edition


Brilliantly fast

With faster, intelligent, multi-core technology that applies processing power where it's needed most, new Intel® Core™ i7 processors deliver an incredible breakthrough in PC performance. They are the best desktop processors on the planet.¹

You'll multitask applications faster and unleash incredible digital media creation. And you'll experience maximum performance for everything you do, thanks to the combination of Intel® Turbo Boost technology² and Intel® Hyper-Threading technology (Intel® HT technology)³, which maximizes performance to match your workload.

Product information

  • 2.93 GHz and 2.66 GHz core speed
  • 8 processing threads with Intel® HT technology
  • 8 MB of Intel® Smart Cache
  • 3 Channels of DDR3 1066 MHz memory

Features and benefits

Go to the next level of multi-core performance.

Intel Core i7 processors deliver an incredible breakthrough in quad-core performance and feature the latest innovations in processor technologies:

Intel® Turbo Boost technology maximizes speed for demanding applications, dynamically accelerating performance to match your workload—more performance when you need it the most.²

Intel® Hyper-Threading technology enables highly threaded applications to get more work done in parallel. With 8 threads available to the operating system, multi-tasking becomes even easier.³

Intel® Smart Cache provides a higher-performance, more efficient cache subsystem. Optimized for industry leading multi-threaded games.

Intel® QuickPath Interconnect is designed for increased bandwidth and low latency. It can achieve data transfer speeds as high as 25.6 GB/sec with the Extreme Edition processor.

Integrated memory controller enables three channels of DDR3 1066 MHz memory, resulting in up to 25.6 GB/sec memory bandwidth. This memory controller's lower latency and higher memory bandwidth delivers amazing performance for data-intensive applications.

Intel® HD Boost significantly improves a broad range of multimedia and compute-intensive applications. The 128-bit SSE instructions are issued at a throughput rate of one per clock cycle, allowing a new level of processing efficiency with SSE4 optimized applications.

Intel® Core™ i7 Processor Extreme Edition










Detailed Description

Model
Brand Intel
Series Core i7
Model BX80601965
CPU Socket Type
CPU Socket Type LGA 1366
Tech Spec
Core Nehalem
Multi-Core Quad-Core
Name Core i7 Extreme Edition 965
Operating Frequency 3.2GHz
QPI 6.4GT/s
L2 Cache 4 x 256KB
L3 Cache 8MB
Manufacturing Tech 45 nm
64 bit Support Yes
Hyper-Threading Support Yes
Virtualization Technology Support Yes
Voltage 0.80V-1.375V
Thermal Power 130W
Cooling Device Heatsink and Fan included

Product information

  • 3.20 GHz core speed
  • 8 processing threads with Intel® HT technology
  • 8 MB of Intel® Smart Cache
  • 3 Channels of DDR3 1066 MHz memory

Features and benefits

Get extreme with your gaming and advanced multimedia.

Intel Core i7 processors deliver an incredible breakthrough in quad-core performance and feature the latest innovations in processor technologies:

  • Intel® Turbo Boost technology maximizes speed for demanding applications, dynamically accelerating performance to match your workload-more performance when you need it the most.²
  • Intel® Hyper-Threading technology enables highly threaded applications to get more work done in parallel. With 8 threads available to the operating system, multi-tasking becomes even easier.³
  • Intel® Smart Cache provides a higher-performance, more efficient cache subsystem. Optimized for industry leading multi-threaded games.
  • Intel® QuickPath Interconnect is designed for increased bandwidth and low latency. It can achieve data transfer speeds as high as 25.6 GB/sec with the Extreme Edition processor.
  • Integrated memory controller enables three channels of DDR3 1066 MHz memory, resulting in up to 25.6 GB/sec memory bandwidth. This memory controller's lower latency and higher memory bandwidth delivers amazing performance for data-intensive applications.
  • Intel® HD Boost significantly improves a broad range of multimedia and compute-intensive applications. The 128-bit SSE instructions are issued at a throughput rate of one per clock cycle, allowing a new level of processing efficiency with SSE4 optimized applications.
